TruPortal Dual Door Interface Module Quick Reference 9

Figure 14: Mounting in AL400 Enclosure without Mounting Plate Figure 15: Mounting in AL600 Enclosure without Mounting Plate

Callout Description

1 TP-ADD-2D

2 TP-ADD (AL400) enclosure

3 #6-32 x 1.00 in. (25.4 mm) plastic standoff, 4 holes

4 #6-32 x .312 in. (7.925 mm), 4 holes

Callout Description

1 TP-ADD-2D

2 TP-ADD (AL600) enclosure

3 #6-32 x 1.00 in. (25.4 mm) plastic standoff, 4 holes

4 #6-32 x .312 in. (7.925 mm), 4 holes
