Intermec CK3X - EA30 Typical Reading Distances - Extended Reading Range

Appendix A — Specifications
CK3R and CK3X Mobile Computer User Manual 99
EA30 Typical Reading Distances - Extended Reading Range
These typical reading distances are measured in an office environment
(250 lux) for the EA30 standard model with Extended Reading Range
activated. Extended Reading Range is enabled by default.
EA30 Typical Reading Distances - Extended Reading Range Activated
4"
8"
0"
4"
8"
12"
12"
cm
0.5 mm / 20 mils
1 mm / 40 mils
in
0" 36" 40"32"28"24"20"16"12"8"4"
0908070605040302010
100
EAN/UPC
0.125mm/5 mils
10
0
10
20
20
30
30
PDF417 10 mils
Data Matrix 10 mils
EA30 Typical Reading Distances - Extended Reading Range Activated
Symbology Density Minimum Distance Maximum Distance
Code 39 0.125 mm/5
mils0.50 mm/20
mils1 mm/40
mils
6.50 cm/2.56
in7.00 cm/2.76
in14.50 cm/5.71 in
24.50 cm/9.65
in62.50/24.61
in97.50 cm/38.39
in
EAN/UPC 100% 0.33 mm/13 mils 6 cm/2.36 in 40 cm/15.75 in
