Two screws
Two cable clips
Cutter cover
Cutter spring
Two screws
(for plastic)
Cutter Mechanism
EasyCoder PD41/PD42 Cutter Kit Installation Instructions 3
Installing the Cutter
1 Unpack your cutter kit and check that all parts depicted below are included.
If not, contact your Intermec sales representative.
2 Make sure the printer is turned off and disconnected from the power
supply. Remove the screw that holds the front cover. Remove the front
cover.

Other manuals for Intermec EasyCoder PD41

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intermec EasyCoder PD41 and is the answer not in the manual?

Intermec EasyCoder PD41 Specifications

General IconGeneral
Print technologyDirect thermal
Maximum resolution203 x 203 DPI
Standard interfacesRS-232, USB 2.0
Internal memory16 MB
Power requirements100-240 VAC ±10%, 45-65 Hz
Media thickness2.3 - 9.8 mm
Maximum label width104 mm
Maximum label length0.15 m
Maximum roll diameter213 mm
Maximum internal memory1 GB
Supported network protocolsTCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)40 - 104 °F
Operating relative humidity (H-H)20 - 85 %
Weight and Dimensions IconWeight and Dimensions
Depth453 mm
Width273 mm
Height270 mm
Weight13000 g
