Intermec EasyCoder PD41 Installation Instructions

EasyCoder PD41/PD42 Cutter Kit Installation Instructions 7
Installing Media
To install media in the printer, follow the instructions provided in the printer’s
user’s guide. e cutter is primarily intended to cut paper-based media in the
form of continuous stock. To obtain optimal use of the cutter, make sure your
media corresponds to the specification below.
Recommended minimum label/paper length 30 mm
Maximum label/paper width 114 mm
Recommended media thickness 78 - 175 μm
Configure your cutter so that it only cuts through the label liner.
If you cut through both label and liner, the adhesive sticks to the
cutting blade and this causes malfunction. Also avoid cutting
soft, plastic-based media.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
