Intermec PF8T User Manual

Appendix A — Printer Specifications
PF8d and PF8t Desktop Printer User’s Guide 67
Internal Interface
Use this table to understand the internal interface for the PF8.
Media Specifications
Direct Thermal Media
Intermec offers a premium and an economy grade of direct thermal
media for the PF8 printers.
Premium Quality
Top-coated media with high demands on printout quality and
resistance against moisture, plasticizers, and vegetable oils.
Internal Interface Pins and Descriptions
Pin UART1 Wafer Ethernet Module
1N.C N.C
2TXD RXD
3RXD TXD
4CTS RTS
5 GND GND
6RTS CTS
7 E_MD E_MD
8RTS CTS
9 E_RST E_RST
10 +5V +5V
11 GND GND
12 +5V +5V
Examples of Premium Quality Media
Europe North America
Thermal Top Board Duratherm Lightning
Thermal Top Duratherm IR
Thermal Top High Speed

Intermec PF8T Specifications

General

Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Core diameter	25.4 mm
Ribbon length	274.32 m
Maximum media length	1727 mm
Maximum roll diameter	127 mm
Supported paper width	118 mm
Maximum media length (imperial)	68 \
Supported paper width (imperial)	4.65 \
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Form factor	Desktop
Dimensions (WxDxH)	168 x 218 x 116 mm
Flash memory	4 MB
Certification	CE, FCC Class A, cULus, UL, GS, TUVGS, CCC, C-TICK, BSMI
Internal memory	8 MB
Built-in barcodes	MaxiCode, PDF417
Page description languages	EPL
Compatible operating systems	Windows 98/Me/2000/XP Pro/Server 2003/Vista
Storage temperature (T-T)	40 - 104 °F
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	100–240 V AC/50–60 Hz, 1.9 A
AC adapter output current	3 A
AC adapter output voltage	24 V

Weight and Dimensions

Weight	2000 g
