Interroll 80i User Manual

Interroll Drum motor series i, S, S/A, D
Version 4.1 (06/2015) en-US
Translation of original instruction manual
3
Table of Contents
Introduction 7
Information about the manual 7
Contents 7
The instruction manual is part of the product 7
Warning notices in this manual 7
Symbols 8
Safety 9
State of the art 9
Intended use 9
Unintended use 9
Personnel qualification 10
Operators 10
Service personnel 10
Electricians 10
Dangers 10
Bodily injury 10
Electricity 10
Oil 10
Rotating parts 10
Hot motor parts 11
Working environment 11
Faults during operation 11
Maintenance 11
Accidental motor start 11
Interfaces to other devices 11
General technical information 12
Product description 12
Options 12
Technical data 13
Product identification 13
Thermal protection 14
Standard design: Temperature limiter, automatically switching back 14
Optional version: PTC (positive temperature coefficient) 15
Use of 50-Hz motors on 60-Hz supply system 15
Effect of using a motor with 50-Hz rated motor voltage on a 60-Hz
supply system 15
Effect of using a motor with 50-Hz rated motor voltage on a 60-Hz
supply system with 15/20 % higher voltage 16
i-series product information 17
Type plate of i-series drum motor 17
