PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
16’ (488 cm) & below Easy Set
®
pools
17’ (518 cm) & above Easy Set
®
pools
2
3
1
3
1
REF
NO.
DESCRIPTION
POOL SIZE & QUANTITIES
6’
(183 cm)
8’
(244 cm)
10’
(305cm)
12’
(366cm)
13’
(396cm)
15’
(457cm)
16’
(488cm)
18’
(549cm)
1 POOL LINER (DRAIN VALVE CAP INCLUDED)
1 1 1 1 1 1 1 1
2 STRAINER HOLE PLUG (OPTIONAL, WITH 1 EXTRA)
3 3 3 3 3 3 3
3 GROUND CLOTH (OPTIONAL)
1 1 1
4 DRAIN CONNECTOR
1 1 1 1 1 1 1 1
5 DRAIN VALVE CAP
1 1 1 1 1 1 1 2
REF
NO.
DESCRIPTION
6’ X 20”
(183cm X 51cm)
8’ X 30”
(244cm X 76cm)
8’ X 30”
(244cm X 76cm)
Clearview
10’ X 30”
(305cm X 76cm)
10’ X 30”
(305cm X 76cm)
Printing
12’ X 30”
(366cm X 76cm)
12’ X 30”
(366cm X 76cm)
Printing
12’ X 33”
(366CM X 84CM)
12’ X 36”
(366cm X 91cm)
SPARE PART NO.
1 POOL LINER (DRAIN VALVE CAP INCLUDED)
11588 12128 11246 12129 11303 10200 11304
11155
10319
2 STRAINER HOLE PLUG (OPTIONAL, WITH 1 EXTRA)
10127 10127 10127 10127 10127 10127 10127
10127
10127
3 GROUND CLOTH (OPTIONAL)
4 DRAIN CONNECTOR
10201 10201 10201 10201 10201 10201 10201
10201
10201
5 DRAIN VALVE CAP
10649 10649 10649 10649 10649 10649 10649
10649
10649
REF
NO.
DESCRIPTION
13’ X 33”
(396cm X 84cm)
15’ X 33”
(457cm X 84cm)
15’ X 36”
(457cm X 91cm)
15’ X 42”
(457cm X 107cm)
15’ X 48”
(457cm X 122cm)
16’ X 42”
(488cm X 107cm)
16’ X 48”
(488cm X 122cm)
18’ X 48”
(549cm X 122cm)
18’ X 52”
(549cm X 132cm)
SPARE PART NO.
1 POOL LINER (DRAIN VALVE CAP INCLUDED)
12130
10622 10183 10222 10415 10436 10623 10320 10765
2 STRAINER HOLE PLUG (OPTIONAL, WITH 1 EXTRA)
10127
10127 10127 10127 10127 10127 10127
3 GROUND CLOTH (OPTIONAL)
18932 18932 18932 18927 18927 18933
18933
4 DRAIN CONNECTOR
10201
10201 10201 10201 10201 10201 10201 10201
10201
5 DRAIN VALVE CAP
10649
10649 10649 11044 11044 11044 11044 11044
11044
4
5
