Intex GRAPHITE GRAY PANEL POOL SET 15'8" User Manual

120
PO
SAVE THESE INSTRUCTIONS
(120PO) ENGLISH 7.5” X 10.3” PANTONE 295U 10/10/2018
English
Page 7
REF.
NO.
DESCRIPTION
15’8” x 49”
(478 cm x 124 cm)
18’8” x 53”
(569 cm x 135 cm)
QUANTITIES SPARE PART NO. QUANTITIES SPARE PART NO.
1
PIN(WITH2EXTRA)
32 10312
38 10312
2
SEAL(WITH2EXTRA)
32 10648
38 10648
3
T - JOINT
15 10861
18 10862
4
SPRINGPIN
15 10313
18 10313
5
VERTICALLEG(SPRINGPININCLUDED)
15 10864
18 10865
6
LEGCAP
15 10309
18 10309
7
HORIZONTALBEAM
15 10414
18 10414
8
POOLLINER(DRAINVALVECAPINCLUDED)
1 11490E
1 11110E
9
DRAINCONNECTOR
1 10184
1 10184
10
DRAINVALVECAP
1 11044
1 11044
11
GROUNDCLOTH
1 18927
1 11290
12
WATERPROOFCAP(WITH4EXTRA)
34 12172
40 12172
13
BOLT(WITH4EXTRA)
34 12173
40 12173
14
TOP CLAMP COVER
15 12174
18 12174
15
TOPBOARD
15 12199
18 12199
16
TOP CLAMP
15 12200
18 12200
17
SUPPORTPOST
15 12201
18 12202
18
PLUNGERVALVECONNECTOR
1 11040
1 11040
19
STRAINERVALVECAP
2 11240
2 11240
20
SIDEBOARDA
116 12203
141 12203
21
SIDEBOARDB
0 -
17 12204
22
SIDEBOARDCOMBINATIONWITHTWOHOLES
1 12205
1 12205
23
SIDEBOARDCOMBINATIONWITHONEHOLE
1 12206
1 12207
24
BOTTOM RAIL
15 12208
18 12208
25
BOTTOM CAP
15 12218
18 12218
26
BOLTWRENCH
2 11053
2 11053
27
PUMPHOSEWITHNUTS
1 10494
1 10494
28
HOSECLAMP
4 10122
4 10122
29
HOSE
2 11873
2 11873
30
SPLITHOSEPLUNGERVALVE
1 11872
1 11872
31
PUMPHOSEWITHNUTS
1 10720
1 10720
32
PLUNGERVALVE(HOSEO-RING&STEPWASHERINCLUDED)
1 10747
1 10747
33
HOSEO-RING
2 10262
2 10262
34
STEPWASHER
1 10745
1 10745
35
L-SHAPEO-RING
2 11228
2 11228
36
STRAINERNUT
3 10256
3 10256
37
FLATSTRAINERRUBBERWASHER
3 10255
3 10255
38
THREADEDSTRAINERCONNECTOR
2 11235
2 11235
39
ADJUSTABLEPOOLINLETJETNOZZLE
1 12369
1 12369
40
ADAPTORA
2 10849
2 10849
41
SIDEBOARDCOMBINATIONWITHONEHOLE
1 12206
1 12206
42
AIR JET VALVE
1 12363
1 12363
43
INLETTHREADEDAIRCONNECTOR+
1
12371
12372
1
12371
12372
44
AIRJETVALVECAP(NOTSHOWN)
1 12373
1 12373
+Ifapplicable,dependingonthesizeofthefilterpumpfittedwithyourpool,youmustquotethemodel
numbershownonthefilterpumphousingtoorderthecorrectsizeof
“Inlet Threaded Air Connector”
replacement part.
