Intex GRAPHITE GRAY PANEL POOL SET 15'8" User Manual

120
PO
SAVE THESE INSTRUCTIONS
(120PO) ENGLISH 7.5” X 10.3” PANTONE 295U 10/10/2018
English
Page 9
REF. NO. DESCRIPTION
POOL SIZE & QUANTITIES
15’8” x 49”
(478 cm x 124 cm)
18’8” x 53”
(569 cm x 135 cm)
1
PIN(WITH2EXTRA)
32
38
2
SEAL(WITH2EXTRA)
32
38
3
T - JOINT
15
18
4
SPRINGPIN
15
18
5
VERTICALLEG(SPRINGPININCLUDED)
15
18
6
LEGCAP
15
18
7
HORIZONTALBEAM
15
18
8
POOLLINER(DRAINVALVECAPINCLUDED)
1
1
9
DRAINCONNECTOR
1
1
10
DRAINVALVECAP
1
1
11
GROUNDCLOTH
1
1
12
WATERPROOFCAP(WITH4EXTRA)
34
40
13
BOLT(WITH4EXTRA)
34
40
14
TOP CLAMP COVER
15
18
15
TOPBOARD
15
18
16
TOP CLAMP
15
18
17
SUPPORTPOST
15
18
18
PLUNGERVALVECONNECTOR
2
2
19
STRAINERVALVECAP
2
2
20
SIDEBOARDA
116
141
21
SIDEBOARDB
0
17
22
SIDEBOARDCOMBINATIONWITHTWOHOLES
1
1
23
SIDEBOARDCOMBINATIONWITHONEHOLE
1
1
24
BOTTOM RAIL
15
18
25
BOTTOM CAP
15
18
26
BOLTWRENCH
2
2
REF. NO. DESCRIPTION
15’8” x 49”
(478 cm x 124 cm)
18’8” x 53”
(569 cm x 135 cm)
SPARE PART NO.
1
PIN(WITH2EXTRA)
10312
10312
2
SEAL(WITH2EXTRA)
10648
10648
3
T - JOINT
10861
10862
4
SPRINGPIN
10313
10313
5
VERTICALLEG(SPRINGPININCLUDED)
10864
10865
6
LEGCAP
10309
10309
7
HORIZONTALBEAM
10414
10414
8
POOLLINER(DRAINVALVECAPINCLUDED)
11490A
11110A
9
DRAINCONNECTOR
10184
10184
10
DRAINVALVECAP
11044
11044
11
GROUNDCLOTH
18927
11290
12
WATERPROOFCAP(WITH4EXTRA)
12172
12172
13
BOLT(WITH4EXTRA)
12173
12173
14
TOP CLAMP COVER
12174
12174
15
TOPBOARD
12199
12199
16
TOP CLAMP
12200
12200
17
SUPPORTPOST
12201
12202
18
PLUNGERVALVECONNECTOR
11040
11040
19
STRAINERVALVECAP
11240
11240
20
SIDEBOARDA
12203
12203
21
SIDEBOARDB
-
12204
22
SIDEBOARDCOMBINATIONWITHTWOHOLES
12205
12205
23
SIDEBOARDCOMBINATIONWITHONEHOLE
12206
12207
24
BOTTOM RAIL
12208
12208
25
BOTTOM CAP
12218
12218
26
BOLTWRENCH
11053
11053
