(189IO) MODEL CS7221/CS7231 SALTWATER SYSTEM & FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/11/2012
189A
SAVE THESE INSTRUCTIONS
English
Page 8
PARTS REFERENCE
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
REF. NO.
DESCRIPTION QTY.
SPARE
PART NO.
SMALL
AGP
LARGE
AGP
COMMON
PARTS
1 AIR RELEASE VALVE/SEDIMENT RELEASE VALVE 2
10460
2 VALVE O-RING 2
10264
3 THREADED FILTER HOUSING COLLAR 1
10749
4 FILTER HOUSING COVER 1
10750
5 FILTER HOUSING O-RING 1
10325
6 FILTER CARTRIDGE (59900) 1
7 AIR RELEASE VALVE B (WITH O-RING) 1
10725
8 PUMP HOSE WITH NUTS 2
10494
9
WATER TRANSFER HOSE (WITH COLLAR AND 2 HOSE CLAMPS)
1
11583
10 SCREW 2
11519
11 FLOW SENSOR 1
11460
12 ELECTROLYTIC CELL NUT 1
11582
13 ELECTROLYTIC CELL (O-RING C INCLUDED) 1
11578
14 COPPER ELECTRODE 1
11579
15 L-SHAPE O-RING 1
11228
16 O-RING C 1
10717
17 ANGLE JOINT (O-RING D INCLUDED) 1
11584
18 O-RING A 1
11587
19
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
2 10747
20 HOSE O-RING 10262
21 STEP WASHER 10745
22 STRAINER NUT 2 10256
23 FLAT STRAINER RUBBER WASHER 2 10255
24 THREADED STRAINER CONNECTOR 2 11235
25 ADJUSTABLE POOL INLET NOZZLE 1 11074
26 ADAPTOR B (OPTIONAL) 2 10722
27 STRAINER CONNECTOR (OPTIONAL) 2 11070
28 POOL INLET NOZZLE (OPTIONAL) 1 11071
29 STRAINER GRID (OPTIONAL) 1 11072
30 CELL COVER 1 11131
31 COPPER ELECTRODE NUT 1 11580
32 TITANIUM ELECTRODE 1 11581
33 CHLORINE TEST STRIPS 1 19635
34 COPPER TEST STRIPS 1 11254
35
TITANIUM ELECTRODE O-RING 1 11585
36
COPPER ELECTRODE O-RING 1 11586
37
CONTROL STATION 1 11592
38
COLLAR NUT 1 11604
When ordering parts, be sure to quote the model number and part numbers.
