341
PO
SAVE THESE INSTRUCTIONS
(341PO) MODEL SF90110-1 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/01/2021
English
REF. NO. DESCRIPTION QTY. SPARE PART NO.
1 PRESSURE GAUGE 1 11720
2 TANK COVER & 6-WAY VALVE SET 1 11721B
3 DRAIN OUTLET COVER 1 11131
4 CLAMP ASSEMBLY 1 11722
5 TANK O-RING 1 11728
6 SAND FILTER PUMP MOTOR INLET O-RING 1 10712
7 CENTER PIPE 1 11729
8 FILTER GRID 1 11730
9 DRAIN VALVE CAP 1 11456
10 DRAIN VALVE O-RING 1 11385
11 L-SHAPE O-RING 4 11228
12 HOSE WITH NUTS 2 11009
13 SAND FILTER INTERCONNECETING HOSE 1 11763
14
1 12365
15
1 12373
16 CLAMP PIN 1 11726
17 CLAMP SCREW 1 11727
18 L-SHAPE O-RING 1 11412
19 TRANSPARENT LEAF TRAP 1 11733
20 PUMP MOTOR 1 12703
21*
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
2 10747
22*
HOSE O-RING
2 10262
23* STEP WASHER 2 10745
24* STRAINER NUT 2 10256
25* FLAT STRAINER RUBBER WASHER 2 10255
26* THREADED STRAINER CONNECTOR 1 10744
27* ADJUSTABLE POOL INLET JET NOZZLE 1 12369
28* ADAPTOR B 2 10722
29* STRAINER CONNECTOR 1 11070
30* POOL INLET JET NOZZLE 1 12364
31* STRAINER GRID 1 11072
32 10" SAND FILTER PUMP TANK 1 12711
33 10" SAND FILTER PUMP TANK BASE 1 12715
34
1 10253
35 AIR RELEASE VALVE 1 10725
36 VALVE
O-RING
1 10264
37* AIR JET VALVE 1 12363
38* INLET THREADED AIR CONNECTOR 1 12371
39* POOL INLET AIR ADAPTOR 1 12368
INLET STRAINER CONNECTOR
AIR JET VALVE CAP (NOT SHOWN)
STRAINER GRID
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts.
Page 6
* If this pump was not purchased as part of a pool set, the above parts can be ordered at
www.intexcorp.com if needed.
When ordering parts, be sure to quote the model number and part numbers.
