254
PO
S AVE THESE INSTRUCTIONS
(254PO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 05/12/2017
English
Page 6
When ordering parts, be sure to quote the model number and part numbers.
PARTS (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
REF.
NO.
DESCRIPTION QTY.
PART NO.
4 ADULTS 6 ADULTS
28403
28405 28407 28409
1 CONTROL BASE 1 12097 12097B 12097 12097B
2 CONTROL BASE BACK COVER 1 11719 11719B 11719 11719B
3 CONTROL PANEL (INCLUDED #4) 1 11930 11930B 11930 11930B
4 CONTROL PANEL BOLT 3 11024 11024B 11024 11024B
5 CONTROL BASE INFLATION CAP 1 11831 11831B 11831 11831B
6 CONTROL PANEL BOLT WRENCH 1 11053 11053 11053 11053
7 SPA/COVER INFLATION HOSE 1 11830 11830 11830 11830
8 SPA CONTROL INLET/OUTLET O-RING 2 11699 11699 11699 11699
9 SPA CONTROL AIR INLET O-RING 1 11687 11687 11687 11687
10 SPA DRAIN PLUG 1 11696 11696B 11696 11696B
11 SPA DRAIN VALVE ADAPTOR 1 11713 11713 11713 11713
12 FILTER CARTRIDGE HOUSING 2 11798 11798 11798 11798
13 FILTER CARTRIDGE 2 11692 11692 11692 11692
14 FILTER CARTRIDGE HOUSING LID 2 11797 11797 11797 11797
15 INLET/OUTLET PLUG 3 11739 11739 11739 11739
16 SPA TUB 1 11843 12259 12105 12257
17 SPA COVER 1 11841 12261 12107 12256
18
SPA COVER INFLATABLE BLADDER
(PRE-INSTALLED IN SPA COVER)
1 11689 11689 12108 12108
19 GROUND CLOTH 1 11717 11717 12109 12109
20 CHEMICAL DISPENSER 1 11614 11614 11614 11614
21 TEST STRIPS 1 11855 11855 11855 11855
22 WRENCH 1 11742 11742 11742 11742
23 AIR PRESSURE RELEASE VALVE CORE 1 12589 12589B 12589 12589B
24 SUCTION FITTING 3 11695 11695 11695 11695
25 INFLATION HOSE ADAPTOR 1 11829 11829 11829 11829
26 MALE BUCKLE 6 11698 11698B 11698 11698B
27 FEMALE BUCKLE 6 11799 11799B 11799 11799B
28 DEFLATION OUTLET CAP 1 11934 11934B 11934 11934B
29 DEFLATION HOSE ADAPTOR 1 11935 11935 11935 11935
30 SPA FILTER MOTOR 1 11885 11885B 11885 11885B
SPA SUCTION FITTING
Self-contained spa fi ttings. – For multiple outlet use only. – Wall mounting only.
Replace suction fi ttings within 3 installed year. – Tool required: screwdriver.
Spa suction fi tting maximum fl ow rate: 8.5 gpm (510 gph)
• Check suction strainer fi tting and fasteners for damage or tampering before each use of the spa.
• For service and winterization instructions refer to “Maintenance” and “Storage” sections.
• Read and follow all instructions, save these instructions for future reference.
