When ordering parts, be sure to quote the model number and part numbers.
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
PARTS REFERENCE
REF. NO. DESCRIPTION QTY.
SPARE PART
NO.
1 PRESSURE GAUGE 1 11411
2 6-WAYVALVE 1 11378
3 DRAIN OUTLET COVER 1 11131
4 CLAMP 1 11380
5 TANK O-RING 1 11379
6 SAND SHIELD 1 11382
7
CENTER PIPE HUB
1 11383
8 LATERAL 10 11384
9 DRAIN VALVE CAP 1
11456
10 DRAIN VALVE O-RING 1 11385
11 L-SHAPE O-RING 4 11228
12 HOSE WITH NUTS 2 11009
13 SAND FILTER INTERCONNECTING HOSE 1 11388
14 LEAF TRAP NUT 1 11479
15 LEAF TRAP O-RING 1 11232
16 BASKET 1 11260
17 FILTER HOUSING NUT 1 11261
18 L-SHAPE O-RING 1 11412
19 SEDIMENT RELEASE VALVE 1 10460
20 VALVE O-RING 1 10264
21
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
2 10747E
22
HOSE O-RING
2 10262
23
STEP WASHER
2 10745
24
STRAINER NUT
2 10256
25
FLAT STRAINER RUBBER WASHER
2 10255
26
THREADED STRAINER CONNECTOR
2 11235
27
ADJUSTABLE POOL INLET NOZZLE
1 11074
28
ADAPTOR B
2 10722
29
STRAINER CONNECTOR
2 11070
30
POOL INLET NOZZLE
1 11071
31
STRAINER GRID
1 11072
32
SCREW
2 11381
33
PUMP MOTOR & CONTROL
1 11387EG
34
PRE-FILTERASSEMBLY
1 11371
35 LEAF TRAP COVER 1 11480
36 VACUUM RELEASE VALVE 2 11437
37 VACUUM RELEASE VALVE CAP 2 11576
38 SAND FILTER PUMP MOTOR INLET
O-RING 2 11457
39 14” SAND FILTER PUMP AND COMBO TANK 1 11498
40 14” SAND FILTER PUMP TANK BASE 1 11513
