MATERIAL JAM IN THE INLET CHUTE:
-
ckage occurs at the cutting system. Turn the
The cutting system runs in reverse and free up
excess materials.
continue processing with a smaller amount of
material.
-
-
MOTOR FAILURE:
release interrupts the power supply and the ma-
chine comes to a standstill.
operation after a cool-down period of approxima-
tely 5 to 10 minutes.
FAULT CHECKLIST:
should check the following:
plugged into the mains power
supply?
mains switch (1) turned on?
selector switch (2) turned on?
material jam in the inlet chute?
motor overloaded?
phase failure?
If you still cannot isolate the fault after carrying
out all these checks, please notify our customer
service department.
-
GEAR BOX MAINTAINANCE:
drive chains must be greased monthly.
Proceed as follows:
1.
cover from the housing.
2.
available grease.
3.
machine to the mains. The machine can be
put back into operation.
-
IMPORTANT SAFETY NOTES
<< The machine may not be operated by more
than one person at any given time!
The machine was designed for safe operation
<< During the shredding process no other
work may be performed on the machine
(for example cleaning, etc.)!
<< The machine is not a toy, and is not suitable
for use by children!
The overall technical safety concept of
emergency shutdown devices etc.) does not
free operation by children.
<< Danger of injury! Keep all loose
articles of clothing, ties, jewe-
lery, long hair or other loose
objects away from opening!
<< Danger of injury!Neverinsertngersinto
opening!
<< In case of danger switch the machine off
with the mains switch, or with the emer-
gency switch, or unplug the machine!
<< Always unplug the machine from the mains
power supply before opening the machine!
Repairs may only be performed by trained
personnel!
5
88034 11 06/15
PacMaster S
MALFUNCTIONS
MAINTENANCE
TECHNICAL DATA
Cutting width: 4x110 mm
Cutting capacity: 2 layers cor. board
quality 3.1
(max. thickness of
cor. boards 18 mm)
Inlet guide
cutting system: 15 mm
Working width
cutting system: 425 mm
Cutting speed:
Power consumption:
Power output: 2.2 kW
Supply voltage:
Pre-fusing:
400V-415V: 16 A
200V-230V: 25 A
Width: 685 mm
Depht: 470 mm
Height:
Noise level: approx. 68.5 dB(A)
Weight: approx. 176 kg
ACCESSORIES
CONNECTION OF VACUUM CLEANER:
-
table for the connection of all common
industrial vacuum cleaners.
Note: For orders of special accessories and spare
DISPOSING OF THE MACHINE:
Dispose of the machine in an
environmentally sound fashion at the end
of its useful service life. Do not dispose of
any of the parts included in the machine
or its packaging with household trash.
DISPOSING
Translation of the Original Operation Manual
