Replacing consumables and maintenance unit
- 80 -
IndexTroubleshooting
1
2
Maintenance
5
While expanding the claws of feed
rollers ( ) in outside direction, remove
them from the axial.
Memo
z
If the feed roller is not visible due to darkness,
open the tray side cover (“Removing paper from the
vicinity of Tray Side Cover”(P.24)).
6
Similarly, remove the remaining two
paper feed rollers ( , ).
To Next Page
