Introduction
OVERVIEW
The SV4E-I3C is an all-inclusive solution for I3C-based device interface development, test, and
programming. Containing three instruments in one, this tool can act as a protocol exerciser for testing
and debugging I3C slave or master devices. It can also act as a complete protocol analyzer with fine-
resolution timing analysis and a full suite of conformance test capability. Finally, it contains a deep
vector memory, which allows it to be used as a general purpose I3C device programmer.
All three categories of instrumentation features are accessible simultaneously and in real-time using the
award winning Introspect ESP Software.
QUICK ST ART DOCUMENTAT ION
This Quick Start Manual will provide the information required for a user to get up and running with the
SV4E-I3C Test and Debug Module. Basic hardware and software installation instructions are included
followed by a step-by-step procedure to start sending and manipulating MIPI I3C commands using the
Introspect ESP Software.
Quick Start Hardware Description
REQ UIREMENTS
The full list of hardware required for this Quick Start Manual is provided below:
• 1 x SV4E-I3C Test and Debug Module
• 1x 12V, 5A volt DC power supply (Manufacturer: CUI, Part # ETSA120500U)
• 2 x Male to male jumper wires
• 1 x I3C Adapter for SV4E
• 1 x Personal Computer connected to the SV4E through a USB mini cable
• Optional: 1 x 1 GHz oscilloscope or higher for signal visualization
