Introspect E Series User Manual

S V 4 E - I 3 C D E M O N S T R A T I O N
SV4E-I3C I3C Test and Debug Module
I N T RO S P E C T . C A
10
SV4E-I3C Demonstration
STEP-BY-STEP G UIDE: DYNAMIC AD DRES SES AND DIRECT READ S
The following step by step guide will allow the user to assign a dynamic address to an I3C slave device
and send it a direct read command from a master device inside the SV4E-I3C. It will also demonstrate
how to visualize the response from the slave, using the mipiI3cDataCapture functionality of the SV4E-
I3C module. The following procedure is intended to provide an overview of how to use the Introspect
ESP Software GUI and highlight several of the GUI’s features.
1. CONNECT THE HARDWARE COMPONENTS
For this procedure, please attach the I3C Adapter for SV4E breakout board to the SV4E-I3C module, and
connect SCL1 and SCL2 together, as well as SDA1 and SDA2, as shown in the following figure.
