SECTION 3—OPERATION

Recessed Side Entry Bath Tubs 26 Part No 1150695

Operating Shower/Massage Wand

NOTE:Forthisprocedure,refertoFIGURE 3.3.

NOTE:STEPS1‐3aretobeperformedwhileholdingtheshower/massagewandoverthetub.

1. Turnshower/massagewandontodesiredflowbyrotatingshowerOn/Offvalve

(Detail“A”).

2. Adjustwatertemperatureusingthewatertemperaturevalvewhilewatchingtheflow

waterthermometer(Detail“B”).

3. Adjustshowerspraybyrotatingshowerwandhead(Detail“C”).

NOTE:Refertofollowingchartforshowerheadadjustmentsettings.

4. TurnshowerOn/Offvalvetooffpositionwhenfinished.

FIGURE 3.3 Operating Shower/Massage Wand

Filling Tub

NOTE:Forthisprocedure,refertoFIGURE 3.4onpage27.

1. Closethedrain(Detail“A”).

2. TurntubfillOn/OffvalvetoOnpositionbyrotatingvalve(Detail“B”).

3. Adjustwatertemperatureusingthewatertemperaturevalvewhilewatchingflow

waterthermometer(Detail“C”).

4. Turntubfillon/offvalvetooffpositionwhenwaterreachesdesiredlevel(Detail“B”).

NOTE:Ifhydromassageuseisanticipated,waterlevelMUSTbecompletelyabovethewhirlpooljets

(Detail“A”).

Stream

Shower Spray

Mixture of Spray and Pulse Massage

Pulse Massage

Water Temperature Valve

Flow Water

Thermometer

Shower On/Off Valve

Shower/Massage

Wand

Head

DETAIL “C”DETAIL “B”DETAIL “A”
