MAINTENANCE
Page 2.21
04/02
2.7 Removing And Replacing Seat Canvas
General
1 Check the seat canvas (4) for any defects (refer to paragraph 3). If any defects are observed then refer to
paragraphs 5 to 6 for maintenance details and to Chapter 3 for parts information.
Tools
2 Refer to the tool list at the beginning of this Chapter.
Inspection
3 Check for the following:
3.1 Damage to seat canvas (4).
3.2 Sagging.
3.3 Reinforcing bar missing and/or damaged.
4 Generally replace and/or tighten any screws (3) or cup washers (2) that are missing/damaged.
Removing The Seat Canvas
5 To remove the seat canvas (4) proceed as follows:
5.1 Unscrew and remove the countersunk head screws (3) and cup washers (2).
Replacing The Seat Canvas
!
Note: Check the order for the correct seat canvas size.
6 Replacing the seat canvas is the reverse of the removal, refer to Chapter 3 for parts information.
