PARTS LIST
Page 3.3
04/02
General
1 This chapter has been split into sections which correspond to the sections in Chapter 2.
2 Refer to the general assembly Figure 3.0 for location of the assemblies covered by the following
sections:
Section Assembly Pages
3.1 Backrest Assembly 6-7
3.2 Armrest Assembly 8-9
3.3 Rear Wheel Assemblies 10-11
3.4 Brake Assemblies 12-13
3.5 Castor Wheel Assemblies 14-15
3.6 Swinging Detachable Footrest Assembly 16-17
3.7 Seat Canvas Assembly 18-19
3 Each section contains the following information in table format:
3.1 Fig/Item reference number
3.2 Part Number
3.3 Description
! Note: The following references are used:
NI When an assembly or component is not illustrated.
Ordering Information
4 To order components or parts information from the relevant address, refer to Chapter 1. Always
quote the following:
4.1 Part Number
4.2 Description
5 For certain orders the following should also be quoted
5.1 Serial or batch number
5.2 End user
