5 FRONT RIGGINGS
Invacare
®
Tracer™ EX2 Wheelchair 32 Part No 1110546
FIGURE1 Installing/Removing Front Riggings
Front Rigging
Release Lever
Front Rigging
Assembly
Footplate
Hinge
Plates
Hinge
Pins
Swingaway footrest shown
