7 SEAT AND BACK
Invacare
®
Tracer™ EX2 Wheelchair 44 Part No 1110546
FIGURE5 Adjusting the Seat Width - Swingaway Front Riggings
DETAIL “B” - CROSSBRACE
HARDWARE (STEPS 4,5)
Crossbrace
Saddle
Washer
Wheelchair Frame
DETAIL “A”
Locknut
Washer
Coved
Washers
Washer
Coved
Washer
Crossbraces
Coved
Washers
Washer
Hex Screw
DETAIL “B”
