10 ANTI-TIPPERS/WHEEL LOCKS
Invacare
®
Tracer™ EX2 Wheelchair 56 Part No 1110546
FIGURE5 Using Patient Operated Wheel Locks
1
/
8
inch (
3
/
16
inch
pneumatic tires)
Wheel Lock
Shoe
Tire
Wheel Lock
Handle
Rear
Wheel
Wheel Lock Shoe
Wheel Lock
Bolt and
Locknut
Mounting
Positions
DETAIL “A”
