65
10. Remove Cross Flow Fan Fan
Motor
11. Remove Ring of Bearing
Bearing
Remove Cross Flow Fan
Fan Motor
1
12. Remove Cross Flow Fan and
Motor Sub-Assy screw.
Removal Procedure
