T
roubleshooting
Page 84
5.12
P2(High temperature pr
otection of IPM module diagnosis and solution)
Description:
If the temperature of IPM module is higher than setting value, the LED displays this failur
e code.
Recommended parts to prepar
e:
•
Faulty PCB
•
Connection problems
T
roubleshooting and r
epair:
Check the fastening screws on the
PCB and IPM radiator.
Are they
fixed tightly?
Replace the outdoor
control PCB.
Tighten the screws and apply
silicon grease.
NO
YES
87
89
