Page 20
Accessories
6
The air conditioning system comes with the following accessories. Use all of the installation parts
and accessories to install the air conditioner. Improper installation may result in water leakage,
electrical shock and re, or equipment failure.
Name Shape Quantity
Indoor unit
installation
Self-tapping screw 3.9×25
2
Flat washers
2
Bushing-sleeve cover
1
Refrigeration
Fittings
Soundproof/insulation
sheath (some models)
2
Drainpipe
Fittings
Drain hose (some models)
1
Band (some models)
2
Drain joint (some models)
1
Seal ring (some models)
1
Installation
Accessory (some
models)
Connection cables
1
Putty
1
Rodent-proof mesh
Self-tapping screw ST3.9×12
1
Remote
controller & Its
Frame (some
models)
1
1
2
1
1
1
1
1
2
Remote controller
Fixing screw for remote
controller holder ST2.9 x 10
Remote controller holder
Dry battery AAA
Owner’s manual
Installation manual
Refrigerant Pipe (optional)
Remote controller illustration
Page 21
Installation Overview
7
L N
1
2
3
4
5
MC MC
6
7
Install the indoor unit
(Page 22)
INSTALLATION ORDER
Install the outdoor unit
(Page 26)
Install the drainpipe
(Page 29)
Evacuate the refrigeration system
(Page 35)
Connect the wires
(Page 33)
Connect the refrigerant pipes
(Page 30)
Perform a test run
(Page 37)
