1. Introduction
Photovoltaic Grid-connected System
1.1 Appearance Introduction
1.2 Parts list
Three Phase String Power Inverter can convert solar panel DC power into AC power
which can directly input to the grid. Its appearance is shown below.These models contain
NITROX- 12KW-3Ph-5G / NITROX-15KW-3Ph-5G / NITROX- 20KW-3Ph-5G /
NITROX-25KW-3Ph-5G
Pic1.1 Front view Pic1.2 Bottom view
Pic1.3 Accessories drawing
1.1 Parts list
Description
PV Solar On Grid Inverter
Wall mounting bracket
Mounting stainless steel screws M4×12
AC power connectors
DC power connectors（including Inserted spring）
Stainless steel Collision bolt M6×80
Square hole sealing plate（Wi-Fi Function selection）
User manual
Wifi-Plug（optional）
No
1
2
3
4
5
6
7
8
9
1
1
4
1
2pairs
4
1
1
1
Qty
Please check the following table, to see whether all the parts are included in the package：
1
6 7
2 3 4
5
8 9
Serial number Description
A
B
C
D
E
Inverter
Metering device
PV strings
Power grid
Family load
Application of inverter in photovoltaic power system
A
B
C D
E
- 01 - - 02 -
To Next Page
