INVT CHV100-2R2G-4 User Manual

List of Function Parameters
116
Function
Code
Name Description
Factory
Setting
Modify LCD Display
P5.17 AI1 upper limit 0.00V~10.00V 10.00V ○ AI1 UP LIMIT
P5.18
AI1 upper limit
corresponding
setting
-100.0%~100.0% 100.0% ○
AI1 UP
SETTING
P5.19
AI1 filter time
constant
0.00s~10.00s 0.10s ○
AI1 FILTER
TIME
P5.20 AI2 lower limit 0.00V~10.00V 0.00V ○
AI2 LOW
LIMIT
P5.21
AI2 lower limit
corresponding
setting
-100.0%~100.0% 0.0% ○
AI2 LOW
SETTING
P5.22
AI2 upper limit
0.00V~10.00V 5.00V ○
AI2 UP LIMIT
P5.23
AI2 upper limit
corresponding
setting
-100.0%~100.0% 100.0% ○
AI2 UP
SETTING
P5.24
AI2 filter time
constant
0.00s~10.00s 0.10s ○
AI2 FILTER
TIME
P5.25 AI3 lower limit -10.00V ~10.00V 0.00V ○
AI3 LOW
LIMIT
P5.26
AI3 lower limit
corresponding
setting
-100.0%~100.0% 0.0% ○
AI3 LOW
SETTING
P5.27
AI3 upper limit
-10.00V ~10.00V 10.00V ○
AI3 UP LIMIT
P5.28
AI3 upper limit
corresponding
setting
-100.0%~100.0% 100.0% ○
AI3 UP
SETTING
P5.29
AI3 filter time
constant
0.00s~10.00s 0.10s ○
AI3 FILTER
TIME
P5.30
AI4 lower limit
0.00V~10.00V 0.00V ○
AI4 LOW
LIMIT
P5.31
AI4 lower limit
corresponding
setting
-100.0%~100.0% 0.0% ○
AI4 LOW
SETTING
P5.32
AI4 upper limit
0.00V~10.00V 10.00V ○
AI4 UP LIMIT
P5.33
AI4 upper limit
corresponding
setting
-100.0%~100.0% 100.0% ○
AI4 UP
SETTING
