INVT CHV100-2R2G-4 User Manual

List of Function parameters
117
Function
Code
Name Description
Factory
Setting
Modify LCD Display
P5.34
AI4 filter time
constant
0.00s~10.00s 0.10s ○
AI4 FILTER
TIME
P5.35
HDI1 function
selection
0 ◎
HDI1
FUNCTION
P5.36
HDI2 function
selection
0: Reference input
1: Counter input
2: Length input
3: Reserved
4: Reserved
0 ◎
HDI2
FUNCTION
P5.37 HDI1 lower limit 0.0 kHz ~50.0kHz 0.0KHz ○
HDI1 LOW
LIMIT
P5.38
HDI1 lower limit
corresponding
setting
-100.0%~100.0% 0.0% ○
HDI1 LOW
SETTING
P5.39 HDI1 upper limit 0.0 kHz ~50.0kHz 50.0KHz ○
HDI1 UP
LIMIT
P5.40
HDI1 upper limit
corresponding
setting
-100.0%~100.0% 100.0% ○
HDI1 UP
SETTING
P5.41
HDI1 filter time
constant
0.00s~10.00s 0.10s ○
HDI1 FILTER
TIME
P5.42 HDI2 lower limit 0.0 kHz ~50.0kHz 0.0KHz ○
HDI2 LOW
LIMIT
P5.43
HDI2 lower limit
corresponding
setting
-100.0%~100.0% 0.0% ○
HDI1 LOW
SETTING
P5.44 HDI2 upper limit 0.0 kHz ~50.0kHz 50.0KHz ○
HDI2 UP
LIMIT
P5.45
HDI2 upper limit
corresponding
setting
-100.0%~100.0% 100.0% ○
HDI2 UP
SETTING
P5.46
HDI2 filter time
constant
0.00s~10.00s 0.10s ○
HDI2 FILTER
TIME
P6 Group: Output Terminals
P6.00 HDO selection
0: High-speed pulse output
1: ON-OFF output
0 ◎
HDO
SELECTION
P6.01 Y1 output selection 1 ○
Y1
SELECTION
P6.02 Y2 output selection
0: NO output
1: Run forward
2: Run reverse
3: Fault output
0 ○
Y2
SELECTION
