INVT CHV100-2R2G-4 User Manual

List of Function Parameters
122
Function
Code
Name Description
Factory
Setting
Modify LCD Display
P7.15 Latest fault type
24: : EEPROM fault (EEP)
25: PID feedback fault
(PIDE)
26: Brake unit fault (BCE)
27: Trial time reached(END)
28: LCD
disconnected(LCD-E)
29: Clock chip fault(TI-E)
30: Reserved
●
CURRENT
FAULT
P7.16
Output frequency at
current fault
● FAULT FREQ
P7.17
Output current at
current fault
● FAULT CURR
P7.18
DC bus voltage at
current fault
●
FAULT DC
VOLT
P7.19
Input terminal
status at current
fault
●
FAULT Sx
STATUS
P7.20
Output terminal
status at current
fault
●
FAULT DO
STATUS
P8 Group: Enhanced Function
P8.00 Acceleration time 1 0.0~3600.0s 20.0s ○ ACC TIME 1
P8.01 Deceleration time 1 0.0~3600.0s 20.0s ○ DEC TIME 1
P8.02 Acceleration time 2 0.0~3600.0s 20.0s ○ ACC TIME 2
P8.03 Deceleration time 2 0.0~3600.0s 20.0s ○ DEC TIME 2
P8.04 Acceleration time 3 0.0~3600.0s 20.0s ○ ACC TIME 3
P8.05 Deceleration time 3 0.0~3600.0s 20.0s ○ DEC TIME 3
P8.06 Jog reference 0.00~P0.07 5.00Hz ○ JOG REF
P8.07
Jog Acceleration
time
0.0~3600.0s 20.0s ○
JOG ACC
TIME
P8.08
Jog Deceleration
time
0.0~3600.0s 20.0s ○
JOG DEC
TIME
P8.09 Skip frequency 1 0.00~P0.07 0.00Hz ○ SKIP FREQ 1
P8.10 Skip frequency 2 0.00~P0.07 0.00Hz ○ SKIP FREQ 2
