List of Function parameters
123
Function
Code
Name Description
Factory
Setting
Modify LCD Display
P8.11
Skip frequency
bandwidth
0.00~P0.07 0.00Hz
SKIP FREQ
RANGE
P8.12 Traverse amplitude
0.0~100.0% (with reference
to P0.10)
0.0%
TRAV
AMPLITUDE
P8.13 Jitter frequency 0.0~50.0% 0.0% JITTER FREQ
P8.14
Rise time of
traverse
0.1~3600.0s 5.0s
TRAV RISE
TIME
P8.15 Fall time of traverse 0.1~3600.0s 5.0s
TRAV FALL
TIME
P8.16 Auto reset times 0~3 0
AUTO RESET
TIMES
P8.17 Fault relay action
0: Disabled
1: Enabled
0
FAULT
ACTION
P8.18 Reset interval 0.1~100.0s 1.0s
RESET
INTERVAL
P8.19 Preset length 1~65535 1000
PRESET
LENGTH
P8.20 Actual length 0~65535 0
ACTUAL
LENGTH
P8.21
Number of pulse
per cycle
0.1~6553.5 100.0
PULSE
NUMBER
P8.22 Preset count value 1~65535 1000
PRESET
COUNT
P8.23
Specified count
value
1~65535 1000
SPECIFIED
COUNT
P8.24 Preset running time 0~65535h 65535 h
RUNNING
TIME
P8.25 FDT level 0.00~ P0.07 50.00Hz FDT LEVEL
P8.26 FDT lag 0.0~100.0% 5.0% FDT LAG
P8.27
Frequency arrive
detecting range
0.0~100.0% (maximum
frequency)
0.0% FAR RANGE
P8.28 Droop control 0.00~10.00Hz 0.00Hz
DROOP
CONTROL
P8.29
Auxiliary motor
selection
0: Invalid
1: Motor 1 valid
2: Motor 2 valid
3: Both valid
0
AUXILIARY
MOTOR
