Goodrive20 inverters Function Parameters
69
Function
code
Name Detailed instruction of parameters
Default
value
Modify
LED tens: frequency control selection
0:Only valid when P00.06=0 or P00.07=0
1:Valid for all frequency setting manner
2:Invalid for multi-step speed when multi-step speed has the
priority
LED hundreds: action selection during stopping
0:Setting is valid
1:Valid during running, cleared after stopping
2:Valid during running, cleared after receiving the stop
command
LED thousands: / keys and analog potentiometer
integral function
0:The Integral function is valid
1:The Integral function is invalid
P08.43
Integral ratio
of
the keypad
potentiometer
0.01~10.00s 0.10s
P08.44
UP/DOWN
terminals
control setting
0x00~0x221
LED ones: frequency control selection
0:UP/DOWN terminals setting valid
1:UP/DOWN terminals setting valid
LED tens: frequency control selection
0:Only valid when P00.06=0 or P00.07=0
1:All frequency means are valid
2:When the multi-step are priority, it is invalid to the
multi-step
LED hundreds: action selection when stop
0:Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after receiving the stop
commands
0x000
P08.45
UP terminals
frequency
changing ratio
0.01~50.00s 0.50 s
P08.46
DOWN
terminals
frequency
changing ratio
0.01~50.00s 0.50 s
P08.47
Action
selection at
0x000~0x111
LED ones: Action selection when power off.
0x000
