Goodrive20 inverters Function Parameters
48
Function
code
Name Detailed instruction of parameters
Default
value
Modify
P05 Group Input terminals
P05.00
HDI input
selection
0: HDI is high pulse input. See P05.49~P05.54
1:HDI is switch input
0
P05.01
S1 terminals
function
selection
Note: S1~S4, HDI are the upper terminals on the control
board and P05.12 can be used to set the function of S5~S8
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10:Increasing frequency setting(UP)
11:Decreasing frequency setting(DOWN)
12:Cancel the frequency change setting
13:Shift between A setting and B setting
14:Shift between combination setting and A setting
15:Shift between combination setting and B setting
16:Multi-step speed terminal 1
17:Multi-step speed terminal 2
18:Multi-step speed terminal 3
19:Multi- stage speed terminal 4
20:Multi- stage speed pause
21:ACC/DEC time 1
22:ACC/DEC time 2
23:Simple PLC stop reset
24:Simple PLC pause
25:PID control pause
26:Traverse Pause(stop at the current frequency)
27:Traverse reset(return to the center frequency)
28:Counter reset
29:Torque control prohibition
30:ACC/DEC prohibition
31:Counter trigger
32:Reserve
33:Cancel the frequency change setting temporarily
1
P05.02
S2 terminals
function
selection
4
P05.03
S3 terminals
function
selection
7
P05.04
S4 terminals
function
selection
0
P05.05
S5 terminals
function
selection
0
P05.06
S6 terminals
function
selection
0
P05.07
S7 terminals
function
selection
0
P05.08
S8 terminals
function
selection
0
P05.09
HDI terminals
function
selection
0
