Goodrive20 inverters Function Parameters
29
Function
code
Name Detailed instruction of parameters
Default
value
Modify
shifting function (P07.02=3) to change the running direction;
press RUN and STOP/RST simultaneously in running state
to make the inverter coast to stop.
1:Terminal running command channel (“LOCAL/REMOT
flickering)
Carry out the running command control by the forward
rotation, reverse rotation and forward jogging and reverse
jogging of the multi-function terminals
2:Communication running command channel
(“LOCAL/REMOT” on);
The running command is controlled by the upper monitor via
communication
P00.03
Max. output
frequency
This parameter is used to set the maximum output
frequency of the inverter. Users need to pay attention to this
parameter because it is the foundation of the frequency
setting and the speed of acceleration and deceleration.
Setting range: P00.04~400.00Hz
50.00Hz
P00.04
Upper limit of
the running
frequency
The upper limit of the running frequency is the upper limit of
the output frequency of the inverter which is lower than or
equal to the maximum frequency.
Setting range:P00.05~P00.03 (Max. output frequency)
50.00Hz
P00.05
Lower limit of
the running
frequency
The lower limit of the running frequency is that of the output
frequency of the inverter.
The inverter runs at the lower limit frequency if the set
frequency is lower than the lower limit.
Note: Max. output frequency Upper limit frequency
Lower limit frequency
Setting range:0.00Hz~P00.04 (Upper limit of the running
frequency)
0.00Hz
P00.06
A frequency
command
selection
Note: A frequency and B frequency can not set as the same
frequency given method. The frequency source can be set
by P00.09.
0:Keypad data setting
Modify the value of function code P00.10 (set the frequency
by keypad) to modify the frequency by the keypad.
1:Analog AI1 setting(corresponding keypad potentiometer)
2:Analog AI2 setting(corresponding terminal AI2)
3:Analog AI3 setting(corresponding terminal AI3)
Set the frequency by analog input terminals. Goodrive20
series inverters provide 3 channels analog input terminals
as the standard configuration, of which AI1 is adjusting
0
P00.07
B frequency
command
selection
2
