INVT GD350-045G/055P-45-AS-B

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-176-
Function
code
Name
Description
Default
value
Modify
P09.18
Low-frequency
integral time (Ti)
0.00–10.00s
0.90s
○
P09.19
Low-frequency
differential time
(Td)
0.00–10.00s
0.00s
○
P09.20
Low-frequency
point of PID
parameter
switching
0.00–P09.21
5.00Hz
○
P09.21
High-frequency
point of PID
parameter
switching
P09.20–P00.04
10.00Hz
○
P09.22–
P09.28
Reserved
/
/
/
P10––Simple PLC and multi-step speed control
Function
code
Name
Description
Default
value
Modify
P10.00
Simple PLC
mode
0: Stop after running once; the VFD stops
automatically after running for one cycle, and it can
be started only after receiving running command.
1: Keep running in the final value after running
once; The VFD keeps the running frequency and
direction of the last section after a single cycle.
2: Cyclic running; the VFD enters the next cycle
after completing one cycle until receiving stop
command and stops.
0
○
P10.01
Simple PLC
memory
selection
0: No memory after power down
1: Memory after power down; PLC memories its
running stage and running frequency before power
down.
0
○
P10.02
Multi-step
speed 0
Setting range of the frequency in 0
th
–15
th
sections
are -300.0–300.0%, 100% corresponds to max.
output frequency P00.03.
Setting range of the running time in 0
th
–15
th
sections are 0.0–6553.5s (min), the time unit is
determined by P10.37.
When simple PLC operation is selected, it is
required to set P10.02–P10.33 to determine the
running frequency and running time of each
section.
Note: The symbol of multi-step speed determines
the running direction of simple PLC, and the
0.0%
○
P10.03
Running time
of step 0
0.0s(min)
○
P10.04
Multi-step
speed 1
0.0%
○
P10.05
Running time
of step 1
0.0s(min)
○
P10.06
Multi-step
speed 2
0.0%
○
P10.07
Running time
0.0s(min)
○
