Goodrive350 IP55 High-ingress Protection Series VFD Installation Guide
-18-
4.2.6 Vertical installation
Figure 4-5 Vertical installation
Cold air
Windshield
Hot air
Hot air
Cold air
Windshield
Note: During vertical installation, users must install windshield, otherwise, the VFD will
experience mutual interference, and the heat dissipation effect will be degraded.
