INVT GD350-045G/055P-45-AS-B

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-237-
Function
code
Name
Description
Default
value
Modify
4: High-speed pulse HDI
5: Main traction encoder frequency-division
input
P90.05
Linear speed set
through keypad
0.0–100.0%
20.0%
○
P90.06
Diameter of
main traction
0.0–6000.0mm
99.0mm
○
P90.07
Main traction
drive ratio
0.000–60.000
1.000
○
P90.08
Linear speed
ACC time
0.00–600.00s
0.00s
○
P90.09
Linear speed
DEC time
0.00–600.00s
0.00s
○
P90.10
Tension setting
0x00–0x14
Ones place: Tension setting source
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI
Tens place: Multiplier of max. tension (P90.12)
0: 1
1: 10
0x00
◎
P90.11
Tension set
through keypad
0.0–100.0%
10.0%
○
P90.12
Max. tension
When the tens place of P90.10 is 0, the setting
range is 0–60000N.
When the tens place of P90.10 is 1, the setting
range is (0–60000)*10N.
1000N
○
P90.13
Roll diameter
calculation mode
0: Not calculated
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI
5: Linear speed
6: Thickness (of wire)
7: Thickness (of strip)
0
◎
P90.14
Roll diameter
calculation delay
time
0.0–100.0s
1.0s
○
P90.15
Min. roll
diameter
0.0mm–P90.16
50.0mm
○
P90.16
Max. roll
diameter
P90.15–5000.0mm
1000.0
mm
○
P90.17
Initial roll
diameter 1
P90.15–P90.16 mm
100.0 mm
○
