Goodrive350 IP55 High-ingress Protection Series VFD Expansion cards
-305-
The EC-IO502-00 expansion card can be used in scenarios where the I/O interfaces of the
VFD cannot meet the application requirements. It can provide 4 digital inputs, 1 PT100
temperature measurement input (PT1+), 1 PT1000 temperature measurement input (PT2+),
and 2 relay outputs. It is user-friendly, providing relay outputs and digital inputs through
European-type screw terminals and temperature measurement inputs through spring
terminals.
EC-IO502-00 terminal function description
Category
Symbol
Name
Function
Power
PW
External power supply
The working power of digital input is
provided by an external power supply.
Voltage range: 24(-20%)–48VDC(+10%),
24(-10%)–48VAC(+10%)
+24V
Internal power
User power provided by the VFD.
Max. output current: 200mA
COM
Power reference
Common terminal of +24V
Digital input
S5—COM
Digital input 5
Internal impedance: 6.6kΩ
Supported external power: 24(-20%)–
48VDC(+10%), 24(-10%)–48VAC(+10%)
Supporting internal power 24V
Bi-directional input terminals, supporting
NPN/PNP modes
Max. input frequency: 1kHz
All are programmable digital input terminals.
You can set the terminal function via
function codes.
S6—COM
Digital input 6
S7—COM
Digital input 7
S8—COM
Digital input 8
Temperature
detection
input
PT1+
PT100 input
Independent PT100 and PT1000 inputs.
PT1+ connects to PT100, and PT2+
connects to PT1000.
1. Resolution: 1°C
2. Range: -20°C–150°C
3. Detection accuracy: 3°C
4. Supporting offline protection
PT2+
PT1000 input
PT-
Reference input of
PT100/PT1000
Zero potential reference of PT100/PT1000
Relay output
RO3A
Contact A of NO relay 3
RO3 relay output. RO3A: NO; RO3C:
common terminal
Contact capacity: 3A/AC250V, 1A/DC30V
RO3C
Contact C of NO relay 3
RO4A
Contact A of NO relay 4
RO4 relay output. RO4A: NO; RO4C:
common terminal
Contact capacity: 3A/AC250V, 1A/DC30V
RO4C
Contact C of NO relay 4
