INVT Goodrive100-PV Series User Manual

Goodrive100-PV Series Solar Pumping VFD Function parameters
29
Function
code
Name
Detailed illustration of parameters
Default
Modify
P02.09
Mutual inductance
of asynchronous
motor
0.1–6553.5mH
features.
Note: Users cannot
modify the parameters
freely.
Depend
on model
○
P02.10
Non-load current
of asynchronous
motor
0.1–6553.5A
Depend
on model
○
P04 Group SVPWM control
P04.00
V/F curve setting
These function codes define the V/F curve
of GD100-PV series motor 1 to meet the
need of different loads.
0: Straight line V/F curve; applying to the
constant torque load
1: Multi-dots V/F curve
2: Torque-stepdown characteristic curve
(1.3 order)
3: Torque-stepdown characteristic curve
(1.7 order)
4: Torque-stepdown characteristic curve
(2.0 order)
Curves 2–4 apply to the torque loads such
as fans and water pumps. Users can
adjust according to the features of the
loads to get the best performance.
5: Customized V/F(V/F separation); in this
mode, V can be separated from f and f
can be adjusted through the frequency
given channel set by P00.06 or the
voltage given channel set by P04.27 to
4
◎
