INVT HT1110L User Manual

Rated Parameters Set on LCD
True Online 6-20k UPS User Manual
34
Annex A. Rated Parameters Set on LCD
1. Power on LCD
2. Press button
together for 3 seconds, enters in rated setting menu as
below
3. Press button “ENTER” to activate setting function as below. Shadow means the current
parameter can be set now.
4. Input voltage setting is activated. Press to select the rated input voltage.
The voltages are available for customer such as: 110V, 120V, 127V, 200V, 208V, 220V, 230V,
240V.
5. Press “ENTER” button to confirm input voltage selection and activate output voltage
setting menu as below. Press
to select the rated output voltage. Output
voltages are available for customer such as: 110V, 120V, 127V, 200V, 208V, 220V, 230V,
240V.
RATE SET
OP
IP
FREQ HZ 50
V(LN) 230
V(LN) 220
50
230
230
