Inxpect LBK System Installation Instructions

EN
SAF-MI-LBK-SBV-multi-v2.0-print-26000041 |© 2020-2021 Inxpect SpA Installation instructions 25
Procedure
1. Start the application.
2. Click User > Configuration and verify that the number of sensors in the configuration is the same
of the sensors installed.
3. Click Settings > Node IDAssignment.
4. Proceed according to the type of assignment:
If the assignment is... Then...
manual 1. Click DISCOVERCONNECTEDSENSORS to display the
connected sensors.
2. To assign a Node ID, click Assign for the unassigned Node ID
in the Configured sensors list.
3. To change a Node ID, click Change for the already assigned
Node ID in the Configured sensors list.
4. Select the SIDof the sensor and confirm.
automatic 1. Click DISCOVERCONNECTEDSENSORS to display the
connected sensors.
2. Click ASSIGN NODE IDS > Automatic.
semi-automatic Click ASSIGN NODE IDS > Semi-automatic and follow the
instructions displayed.
Chain examples
X
Chain with controller at the end of the chain anda sensor
with termination connector
Y
Chain with controller inside of the chain and two sensors
with termination connector
Save and print the configuration
1. In the application, click APPLY CHANGES: the sensors will memorize the inclination set and the
surrounding environment. The application will transfer the configuration to the controller, and
once transfer is complete it will generate a configuration report.
2. Click to save and print the report.
3. If necessary, complete the report with the inclination and height data of the sensors.
4. Require a signature by the authorized person.Ask the authorized person for a signature.
What to do next
Follow the instructions in the manual to validate the safety functions and manage the configuration.
www.inxpect.com/industrial/tools
