ION 30ACi User Manual

30ACi
Battery Back-Up System
OPERATION MANUAL
Dated: 07/23/2013
Document Name: 30ACi_OM
Page 6 of 12
Register your product at www.sumpro.com
30acI BacK panel
The inverter has two battery leads coming out from the
back of the inverter, with a grey Anderson connector
on the end, a MCB (main circuit breaker), pump
output socket (120 volt) and a power cord to connect
with AC power (120 volt). The Anderson connector
on the inverter leads gets connected to the Anderson
connector on the Pig Tail coming from the battery.
30acI front panel
Pump Outlet
Date of Manufacture Label
120 Volt
Power Cord
Main Circuit Breaker
DC MODEAC MODE
Output VoltageOutput Voltage
Amount of LoadAmount of Load
Battery Display
Battery Display
Charge in
Batteries
Charge in
Batteries
Frequency/
Load Amps
Input
Voltage/
Load Amps
Quick Connect
Battery Leads
Anderson
Connector
Power Button Power Button
