+++ 1010220017 SMD RESISTOR SMT0603,1M,±5% PCS 2.00 R18 R19
+++ 1010401004 SMD diode IN4148 LL-34 PCS 2.00 D3 D4
+++ 1010405002 SMD Stabilivolt Diode
s
5.1V 1/2W LL-34 PCS 1.00 D2
+++ 1010405025 SMD Stabilivolt Diode
s
4.3V 1/2W LL-34 PCS 1.00 D1
+++ 1010401034 SMD diode IN4007 DO-214AC PCS 2.00 D5 D6
+++ 1010303004 MLCC SMT0603,103,±10% PCS 2.00 C11 C12
+++ 1010303006 MLCC SMT0603,104,±10% PCS 2.00 C2 C10
+++ 1010303007 MLCC SMT0603,105,±20% PCS 2.00 C3 C4
+++ 1010303051 MLCC SMT0603,475,±20% PCS 1.00 C6
+++ 1010220133 SMD RESISTOR SMT1206,30R±5% PCS 1.00 R24
+++ 1010220087 SMD RESISTOR SMT1206,220R,±5% PCS 1.00 R10
+++ 1010220144 SMD RESISTOR SMT1206,150K,±5% PCS 4.00 R8 R9 R20 R21
+++ 1010303067 MLCC SMT1206,106,+80%-20% PCS 1.00 C1
2010100396 mechanism JW-30-1 ABS black
+ 2010100384 switch board of the
mechanism
JW-30 SK REV1.0 switch board PCS 1.00
++ 1010110185 PCB board JW-30 SK REV1.0 60×20×1.6MM
94V0-KB sin
g
le board
PCS 1.00
++ 1010210038 Plug in resistance pin distance 5MM 470R,±5% 1/8W PCS 1.00 R1
++ 1012600030 needle file 6P/2.5MM 90 de
g
ree PCS 1.00 CN2
++ 1010902038 to
gg
le switch SS-12F46-G8 3×3 PCS 1.00 SW1
++ 1010902039 to
gg
le switch SS-13E05-G8 3×5 PCS 1.00 SW2
++ 1010250010 ad
j
ustable resistance SR-085 500R PCS 1.00 VR2
++ 1011709003 mechanism line 26# 5P2.5+7P2.0 pin distance +2P
with tin 3MM L=100MM
PCS 1.00 CN1
+ 1013200004 Cartrid
g
e JP , CZ-800-10 PCS 1.00
+ 1011703024 cartrid
g
e line 1P L=310MM white PCS 1.00 cartrid
g
e
+ 1011703025 cartrid
g
e line 1P L=310MM red PCS 1.00 cartrid
g
e
+ 1011703026 cartridge line 2P L=310/50MM black with ground PCS 1.00 cartridge
+ 1010908002 leaf switch SJ-SW-115-2
(
soft
)
PCS 1.00 panel
+ 1014000022 MOTOR 3 spped EG-530SD-
3F
(
33/45/78
)
+5P2.5
PCS 1.00
+ 2020100061 middle panel JW-30-1 ABS black PCS 1.00
+ 2020500039 platte
r
JW-20 ABS black PCS 1.00
+ 2020500029 1.5inch platte
r
JW-20 ABS black PCS 1.00
+ 2020500030 tonearm lift level JW-20 ABS black PCS 1.00
+ 2020500031 tonetube socket JW-20 ABS black PCS 1.00
+ 2020500032 tonearm shaft JW-20 ABS black PCS 1.00
+ 2020500033 arm clip JW-20 ABS black PCS 1.00
+ 2020500034 tonetube buckle JW-20 ABS black PCS 1.00
+ 2020500035 wafe
r
JW-20 ABS black PCS 1.00
+ 2020500036 switch film JW-20 ABS black PCS 1.00
+ 2020500037 switch protective film JW-20 ABS black PCS 1.00
+ 2020500038 screw for motor JW-20 ABS black PCS 3.00
+ 1021200024 PVC pad Ø12.5×7.5×0.3MM PCS 1.00
+ 1013401001 Motor shockproof rubber Ø9×Ø4×5MM
(
45 de
g
ree
)
PCS 3.00
+ 1061600001 bel
t
Ø128×0.5×4.7MM PCS 1.00
+ 1021500002 copper tube Ø6×133×0.25MM silver PCS 1.00
+ 1021400003 E shape sprin
g
pad Ø6 black PCS 1.00
+ 1021200034 Sprin
g
(
s
)
Ø5×7×6T×0.6 PCS 1.00 metal shaft
+ 1020400010 sprin
g
(
s
)
Ø0.25×OD5.0×14T×15L PCS 1.00 switch film
+ 1020400030 metal shaft
(
S
)
Ø2×33MM chrome PCS 1.00 tonearm lift level
+ 1021600006 metal shaft 7.88mm for platter PCS 1.00
+ 1021600003 SCREW 2.6×8.5PM PCS 1.00 middle panel
