ION Complete LP Service Manual

Level Code Name Descri
p
tion unit
q
t
y
location
+ 2050100285 WOODEN TURNTABLE IT61
(
TT15015
)
，ION, NC-D03 PCS 1.00
++ 2010100399 MAIN PCB BOARD TT15015 MAIN LCD-V1.0 Dual side,
half finish
PCS 1.00 half finished
+++ 1010120148 PCB board TT15015 MAIN LCD-V1.0
336×58×1.2MM FR4 with tin, dual
side
PCS 1.00 wooden panel
+++ 1010260050 SMD PRECISION
RESISTANCE
SMT0603,470R,±1% PCS 3.00 R24,R25,R30
+++ 1010260016 SMD PRECISION
RESISTANCE
SMT0603,1K,±1% PCS 2.00 R1,R9
+++ 1010260004 SMD PRECISION
RESISTANCE
SMT0603,1.2K,±1% PCS 2.00 R2,R10
+++ 1010260006 SMD PRECISION
RESISTANCE
SMT0603,1.8K,±1% PCS 4.00 R3,R4,R11,R12
+++ 1010260020 SMD PRECISION
RESISTANCE
SMT0603,2.7K,±1% PCS 2.00 R5,R13
+++ 1010220108 SMD RESISTOR SMT0603,15R,±5% PCS 1.00 R77
+++ 1010220016 SMD RESISTOR SMT0603,1K,±5% PCS 29.00 R14,R15,R16,R18,R1
9,R20,R23,R27,R29,
R31,R35,R39,R40,R4
1,R42,R43,R44,R45,
R48,R51,R52,R53,R5
4,R76,R79,R81,R83,
R86,R87
+++ 1010220018 SMD RESISTOR SMT0603,2.2K,±5% PCS 2.00 R72,R69
+++ 1010220099 SMD RESISTOR SMT0603,10K,±5% PCS 30.00 R17,R21,R22,R32,R3
3,R36,R37,R38,R46,
R47,R49,R50,R55,R5
6,R57,R58,R59,R60,
R61,R62,R63,R65,R6
6,R67,R70,R71,R75,
R80,R82,R85
+++ 1010220043 SMD RESISTOR SMT0603,30K,±5% PCS 2.00 R73,R74
+++ 1010220058 SMD RESISTOR SMT0603,47K,±5% PCS 1.00 R34
+++ 1010220063 SMD RESISTOR SMT0603,51K,±5% PCS 2.00 R68,R64
+++ 1010220007 SMD RESISTOR SMT0603,100K,±5% PCS 2.00 R78,R8
+++ 1010220112 SMD RESISTOR SMT0603,10M,±5% PCS 1.00 R84
+++ 1010303026 MLCC SMT0603,20pF,±5% PCS 2.00 C6,C2
+++ 1010303032 MLCC SMT0603,22pF,±5% PCS 2.00 C38,C37
+++ 1010303001 MLCC SMT0603,100PF,±5% PCS 2.00 C29,C11
+++ 1010303103 MLCC SMT0603,331,±10% PCS 1.00 C14
+++ 1010303003 MLCC SMT0603,102,±10% PCS 5.00 FC3,C18,C24,C32,C
33
+++ 1010303004 MLCC SMT0603,103,±10% PCS 6.00 C7,C8,C9,C10,C30,C
31
+++ 1010303006 MLCC SMT0603,104,±10% PCS 10.00 FC1,FC2,FC4,C5,C1
9,C21,C22,,C34,C35,
C36
+++ 1010303030 MLCC SMT0603,224,±10% PCS 6.00 C12,C16,C17,C23,C2
5,C27
+++ 1010303050 MLCC SMT0603,474,±10% PCS 1.00 C13
Bill of Materials (BOM)
