4
Rear Panel
1. Line Output: Connect external speakers to this output.
2. Speakers: These internal speakers output the music.
3. Bass Ports: These provide extended bass for the music. Position these away from walls
or other obstructions for best sound quality.
4. Tapedeck: Insert a cassette tape here.
5. Power Input: The integrated power cable is connected here.
6. FM Antenna: Adjust this wire for better FM radio reception. For AM reception, rotate the
unit until the best reception is found.
Recording
Note: It is not possible to record from the AM/FM radio.
When in BT/TAPE/PHONO/AUX mode:
1. Connect your USB flash drive to Complete LP.
2. Press USB REC.
3. Press USB REC to begin recording.
4. Once the display shows “REC”, USB flashes in the top left corner of the display,
recording will begin.
5. Press STOP to end recording and it will save the audio file to your USB flash drive.
When in CD/MP3 mode:
1. Connect your USB flash drive to Complete LP.
2. Press USB REC.
3. Press NEXT/PREV to toggle between these options:
• REC ONE (record one track)
• REC DIR (record all songs from the current folder)
• REC ALL (record all the songs)
4. Press USB REC to begin recording. Once the display shows “READING”, USB will flash
on the screen and begin recording.
5. Press STOP to end recording and it will save the audio file to your USB flash drive.
1
2
2
3
4
3
5
FM ANT
6
