ION Explorer - Bill of Materials (BOM)

Bill of Materials (BOM)
Part # Part name Description Qty.
DR00166 IPA76S Semi-ASSY IPA76S Semi-ASSY 1
10530036 Steel support DN-MB6036,M3 screw hole at both sides,L=12mm 3
10530091 Steel support DN-MB6084,low-carbon steel,ROHS,V1.0 2
12030044 Switch AN-S343,RS601D,6A/250V 1
13110012 Switch mode power supply K48P160300-1,100-240VAC,16V/3A,mounting hole Φ4.2mm 1
16040955 Plug with cable AN-W4515,2P,22#,UL1617,130mm 1
16040956 Plug with cable AN-W4516,2P,22#,UL1007,420mm 1
16040957 Plug with cable AN-W4517,2P,20#,UL1007,200mm 1
16120133 Plug with cable AN-WE133,UL1007,22#,200mm 1
20020152 top cover DN-PC2101,ABS,UL94V-0 1
20210156 volume knob DN-PN2115,ABS 2
20320025 Handle DN-PE2025,ABS 2
20360099 handle plastic piece DN-PE6054,ABS 2
20410119 buttons DN-PEB075,(3),ABS 5
20410120 buttons DN-PEB076,(2),ABS 1
20440059 separate post UBD-1,NYLON66(94V-0) 1
20460013 fix button KY-CLT-2 1
40010038 power socket AN-J0138,DB-14-F,3P 1
54020098 top cover DN-PC2101,ABS,UL94V-0 1
60100016 antenna IPA23,AM antenna,AM-D8x100mm-85TS-M7 1
60100017 antenna plastic ntenna,2.4G,2DBi,black,ROHS 1
60190143 FM antenna IPA30,FM plastic antenna，￠9.5*220mm 1
70010046 screw M3*6mm,screw head D6mm 5
70010048 screw AN-C10048,M3*6mm,screw head D5.5mm 5
70010054 screw Φ3*6mm,screw head D5.5mm 5
70010111 screw Φ3*10mm,screw headD5.5mm 10
70010337 screw Φ2.6*8mm,screw headD4.5mm 8
70010576 screw Φ3*6mm,screw headD7.5mm 2
70010605 screw Φ2.6*7mm,screw headD4.5mm 2
CR01079 semi-finished electronics IPA76S MAIN ASSY 1
60190161 LCD display AN-E308,BCD-6516B 1
60210026 NFC module HCR-TAG2-series 1
CR01079 IPA76S MAIN SMT IPA76S MAIN SMT ASSY 1
60210035 BT module IPA23B(AIROHA),AB1511,AIROHA 1
ER00056 packaging materials IPA76S package ASSY 1
10360022 corner DN-ME1016,SPCC,T=0.8mm,black chrome,V1.0 8
10410171 grill DN-ME5126,SPCC,T=0.8mm 1
10520106 wheel JD180D 2
10520185 antenna tin,265*15mm,T=0.3mm,V1.1 1
16040918 plug with cable AN-W4478,1P,18#,UL1015,500mm 1
16040919 plug with cable AN-W4479,1P,18#,UL1015,500mm 1
16040929 plug with cable AN-W4489,2P,18#,UL1015,L=450mm 1
16120138 Plug with cable AN-WE138,1P,UL1007,18#,160mm 1
16141043 multicore electric wire 1P,22#,UL1007,L=350mm 1
16141044 multicore electric wire 1P,22#,UL1007,L=350mm 1
16150041 3.5 plug with cable AN-W1540,UL2547,26#,610mm 1
17050013 nonpolarity electrolytic 4.7uF/50V,±20%,-40/+85℃,Φ6*17mm 1
20110133 len DN-PL1102 1
20660038 rail DN-PC6036,(3),ABS 1
20660039 rail DN-PC6037,(2),ABS 1
