4
TOTAL PA GLOW
Quick Setup
Connection Diagram
Speaker Stand Installation
1. Fully extend the speaker stand tripod legs on a flat, stable
surface. Look in the box contents under the foam sheet for the
rubber feet and speaker stand mounting knob.
2. Raise the mounting pole up to the appropriate height needed
and tighten the side adjustment knob.
3. Insert the pin into the bottom pin-hole so the mounting pole
stays at your set height.
4. On Total PA Glow, adjust the bottom knob counter-clockwise
so the screw is not blocking the opening.
5. Line up the Total PA Glow mounting hole with the speaker
stand pole and place on the pole.
6. Tighten the mounting knob clockwise on Total PA Glow.
3 45/6
Items not listed under
Introduction > Box Contents
are sold separately.
2
1
Tablet
Microphones
SD Card
USB drive
Smartphone
Power
To Next Page
