ION iTT02 User Manual

10
ELECTRICAL PARTS LIST
REF. NO DESCRIPTION PART NO.
Q’TY
MAIN PCB ASS'Y 704-BJ20-2402 1
2P CONNECTOR WIRE(L=200mm,AWM1007 AWG26) 404-BJ20-1013 1
2P BASE(JST ANGLE P=2.5mm WHITE) 404-DJ1900-170 1
5P BASE (JST P=2.5mm WHITE) 404-DJ1900-172 1
3P SOCKET(S3B-XH-A,P=2.5mm) 404-KMD3500-609 1
C101 ELEC. CAPACITOR(1000uF/25V,M,BULK 12.5*20,L) 413-DJ1900-111 1
RELAY(PCE-112D1H) 415-BJ20-149 1
SPEED IC (AN6652) 417-BJ1900-051 1
C102 CERAMIC CAPACITOR(0.1uF/50V Z Y5V TAPING) 413-3113-035 1
C103 ELEC. CAPACITOR(100uF/10V,M,TAPING 5*11) 413-3113-046 1
C105 ELEC. CAPACITOR(4.7uF/50V,M,TAPING 5*11) 413-3113-050 1
C104 MYLAR CAPACITOR(0.01uF J 50V TAPING) 413-3113-057 1
C108 E.CAPACITOR(47uF/25V,M,TAPING 5*11) 413-HS100-181 1
C106,107 POLYESTER CAPACITOR(MYLR 0.022UF/50V TAPING) 413-KT300-101 2
Q105 TRANSISTOR(2SD1384(R)/2SD1207T,TAPING) 416-1360S-016 1
Q101,107 TRANSISTOR(DTC124ES TAPING OR 2SC3400) 416-3113-010 2
Q102-104,106 TRANSISTORS (2SC3330U-AC) 416-DJ1900-023 4
IC101 IC(LM78L05 TAPING TO-92) 417-PMSE1-161 1
MAIN PCB(BARE,394V0,98*90*1.6t) 405-BJ25-525 1
R103,106
CARBON FILM RESISTOR(5.6K OHM J 1/6W TAPING 26mm)
412-3113-044 2
R101
CARBON FILM RESISTOR(33KOHM J 1/6W TAPING 26mm)
412-3113-045 1
R107
CARBON FILM RESISTOR(470OHM J 1/6W TAPING 26mm)
412-3113-056 1
R104,105,111
CARBON FILM RESISTOR(10KOHM J 1/6W TAPING 26mm)
412-3113-068 3
R108
CARBON FILM RESISTOR(510 OHM J 1/6W TAPING 26mm)
412-BJ1900-140 1
R109
CARBON FILM RESISTOR(1.5K OHM J 1/6W TAPING 26mm)
412-D396-135 1
D105-109 SWITCHING DIODE(1SS132/1SS133,300mw,55V,T-77) 414-3113-005 5
DIODE(1N4001,1A/50V,TAPING 52mm)+E498 414-DJ2500-110 5
VR & HIMELON ASS'Y 704-BJ20-2403 1
SLIDE RESISTOR(RS6011YL6003-10KA(HF)) 418-BJ20-070 1
VR CUSHION(75.5*8.5*0.3t) 612-HDJ7000-056A 1
ELECTRICAL PARTS LIST
REF. NO DESCRIPTION PART NO
Q’TY
VELOCITY MODULATE PCB ASS'Y 704-BJ20-2401 1
SPEED CONTROL PCB (BARE,94V0,162*80*1.6t) 405-BJ25-530 1
3P CONNECTOR WIRE(P=2.5mm L=100mm) 404-DJ2500-689 1
R110
CARBON FILM RESISTOR (220 OHM J 1/6W TAPING 26mm)
412-3113-058 1
VR102,103 SEMI-FIXED R (1KB CARBON 3PIN) 412-BJ1900-017 2
