EXPLODED VIEW PARTS LIST
REF. NO DESCRIPTION PART NO.
Q’TY
REMARK
1 CHASSIS 100-BJ20A1-598E 1 20A1
1 CHASSIS 100-BJ20B1-598E 1 20B1/C1
2 BOTTOM COVER 100-BJ20A1-600B 1 20A1
2 BOTTOM COVER 100-BJ20B1-600B 1 20B1/C1
3 DUST COVER(SRAY+PRINT) 100-DJ1900-599 1
4 PLATTER 100-BJ20B1-1559 1
5 SLIPMAT 612-BJ20A1-052 1
6 AC PCB 405-BJ20-532 1
7 45 RPM ADAPTOR 100-H910-264 1
8 POWER BOTTON(ABS,RED) 100-BJ20A1-602 1
9 33/45 RPM DECORATIVE PLATE (PVC 0.5t) 501-BJ20A1-574 1
10 DECORATIVE PLATE 501-BJ20A1-575 1
11 LAMP SHADE 100-DJ1900-591 1
12 STICKER 508-DJ1900-039 1
13 CONTROL PCB ASS’Y 704-BJ20A-2596 1 20A1
13 CONTROL PCB ASS’Y 704-BJ20-2400 1 20B1/C1
14 KNOB ASS'Y(ABS,SILVER) 100-BJ20A1-604 1
15 SCREW 602-2002-077 13
16 POWER SW 403-A100-005 1
17 CAPSTON 200-B300-125 1
18 MOTOR 401-BJ1900-049 1
19 PVC TUBE(UL) 504-HV3500K-033 4
20 SPEED PUSH BUTTON 100-BJ20A1-603A 1
21 DECORATIONS 501-BJ20A1-1326 1
22 FUSE LABEL 501-BJ2300-1298A 1
23 MAIN PCB ASS’Y 704-BJ20-2402 1
24 SCREW 602-SL24F-099 4
25 TRANSFORMER 411-BJ1900-053 1
26 CUSHION RUBBER FOR TRANSFORMER 604-DJ1900-064 2
27 TRANSFORMER LEAF SPRING 603-DJ1900-136 1
28 SCREW 602-B600-056 5
29 TONEARM LIFTER 100-B200-167 1
30 PICK-UP CRAMPER 100-B200-170 1
31 COPPER NAIL 200-B200-093 1
32 SCREW 602-B200-071 1
33 LIFTER 100-B300-115 1
34 LIFTER SPRING 603-DJ2500-208 1
35 SCREW 602-B300-044 1
36 DECORATIVE PLATE FOR ROTATING KNOB 501-BJ20A1-037 1
37 MICRO ADJUST KNOB 100-B300-117 1
38 WASHER 606-B300-032 1
39 CLUTH LEVER KNOB 100-F200-033 1
40 2P RCA JACK 420-BJ1900M-050 1
41 DECORATIVE PLATE 501-BJ2300E-573 1
42 OUTPUT INDICATION LABEL 501-DJ1900-615 1
43 RATING LABEL 501-BJ20A1-719 1
44 SERIES NO LABEL 501-DV300-1067 1
45 TONE ARM ASS’Y 704-BJ20A1-4112 1
45 HEADSHELL 300-BJ20A1-122 1
45 CARTRIDGE 402-H468-004 1
46 COUNTER WEIGHT ADJUSTOR ASS'Y 702-BJ20A1-030 1
47 DECORATIVE PLATE FOR DUST COVER 501-BJ20A1-017 1
48 RUBER 604-BJ2300-026A 2
49 HINGE 100-D750-303 2
50 HINGE SLIDE 100-D750-304 2
To Next Page
