SPECIFICATION
1. APPLICATION:
This specification applies to the belt drive turntable unit iTT02.
2. STANDARD TEST CONDITION:
2-1 Ambient Temperature 23 ±2ºC
2-2 Relative Humidity 65% ±5%
NOTE: Measurements can be carried out between 5ºC to 35ºC and 45% to 85% relative humidity.
3. TURNTABLE SECTION:
3-1 Type 2-speed full manual
3-2 Motor DC motor
3-3 Driving Method Belt drive
3-4 Turntable platter 330mm dia. Plastic
3-5 Speeds 33
1
/
3
and 45 rpm
3-6 Wow and Flutter Less than 0.25% WRMS (JIS WTD)
3-7 S/N ratio More than 50 dB (DIN-B)
3-8 Pitch Controls +/-10%
3-9 Starting Time Less than 1 sec.
3-10 Breaking Time Less than 1 sec.
3-11 Time for speed change Less than 1 sec.
3-12 Speed tolerance at pitch=0 Within +/-1.3%
3-13 High of cue (first track) 6~10mm
4. TONEARM SECTION:
4-1 Type Static balanced S-shaped tonearm with detachable headshell
4-2 Effective Arm Length 220mm
4-3 Overhang 10mm
4-4 Tracking error Less than 3 degree
4-5 Tracking Force Adjustment range 0-4g
4-6 Applicable cartridge weight 6-10g
4-7 Anti-skating range 0-4g
4-8 Tracking force range of attached cartridge 3.5 +/- 0.5g
5. GENERAL SECTION:
5-1 Power Supply AC 115/230V, 50/60Hz
5-2 Power Consumption 8 Watts
5-3 Dimensions 450(W) x 350(D) x 150(H) mm
5-4 Weight 3.75Kgs
6. ACCESORIES SUPPLIED Instruction manual x 1,Headshell x 1, 45 rpm adaptor x 1
7. SPECIFICATION:
DESCRIPTIONS UNIT NORMAL LIMIT
(1)Output Difference dB 2.3 2.5
(2)Output Level mv 1.7~3.5 1.5~3.6
(3)Speed (Speed Range) Hz
2.7K ↓,3.3K ↑ 2.7K ↓,3.27K ↑
(4)Speed (Center Range) Hz 2970~3030 2965~3030
(5)Wow and Flutter % 0.23 0.25
(6)Channel separation dB 16 15
